3–20 T/H Industrial RO Systems With Pre-Treatment Dosing System

This industrial-grade reverse osmosis (RO) system is designed for 2–3 m³/h continuous permeate flow, built for commercial and light industrial facilities requiring reliable, high-volume purified water.

The system features a full pre-treatment chain (multi-media sand filtration + activated carbon filtration), a dedicated chemical dosing system, a precision security filter, and a high-efficiency RO unit. It effectively removes sediment, chlorine, organic contaminants, scaling ions, and dissolved salts, delivering consistent, high-quality water for manufacturing, food & beverage, boiler feed, and general process applications.

Designed for intermittent on-demand operation instead of 24-hour continuous running, it supports flexible start and stop to save energy and reduce equipment wear, perfectly matching places with fixed working hours water demand.

Inquiry

Write a Review

Core Process Flow

3–20 T/H Industrial RO Systems With Pre-Treatment Dosing System 8

⚙️ Multi-Media Filtration (MMF)

Removes suspended solids, sediment, rust, and turbidity from raw water, protecting downstream components and preventing clogging.

3–20 T/H Industrial RO Systems With Pre-Treatment Dosing System 9

⚙️ Activated Carbon Filtration (ACF)

Eliminates residual chlorine, organic compounds, tastes, odors, and color, protecting the RO membrane from oxidation and fouling.

3–20 T/H Industrial RO Systems With Pre-Treatment Dosing System 10

⚙️Chemical Dosing System

A fully integrated dosing station for scale inhibitors, flocculants, or pH adjusters, ensuring optimal feed water conditions for the RO membrane and preventing mineral scaling.

⚙️ Security Filtration

A high-capacity cartridge filter captures fine particulates, acting as the final barrier before the RO membrane to reduce fouling risk.

3–20 T/H Industrial RO Systems With Pre-Treatment Dosing System 12

⚙️ Reverse Osmosis (RO) System

The core purification stage removes over 98% of dissolved salts, heavy metals, bacteria, and other contaminants, producing high-purity water for industrial use.

Technical Specifications

Parameter	Specification
Rated Permeate Flow	3–20 m³/h (3,000–20000 L/h)
System Configuration	MMF → ACF → Dosing System → Security Filter → RO
RO Recovery Rate	50–75% (adjustable based on feed water)
TDS Rejection Rate	≥98%
Dosing Function	Scale inhibitor, flocculant, pH adjustment (configurable)
Tank Material	FRP (Sand & Carbon Filters)
RO Membrane Housing	FRP / Stainless Steel
Control System	Automatic Multiport Valves + RO Control Panel
Operating Temperature	5–45°C
Power Supply	220V/380V, 50/60Hz (Customizable)
Certification	CE Compliant

Benefits for Your Business

• Superior Membrane Protection: The integrated dosing system prevents scale formation, extending the RO membrane’s service life and reducing replacement costs.

• Consistent High-Purity Water: The RO system reliably meets the water quality standards of industrial processes, ensuring product quality and process stability.

• Low Maintenance & Downtime: Automated backwashing, flushing, and dosing control minimize manual intervention and unplanned stops.

• Space-Efficient Layout: The modular design allows for flexible installation in industrial facilities, with clear separation of pre-treatment and RO stages.

• Versatile Applications: Suitable for boiler feed water, manufacturing processes, food & beverage production, agriculture, and commercial use.

📦 What’s Included

2 x FRP tanks (Multi-Media Filter + Activated Carbon Filter) with automatic control valves

1 x dedicated chemical dosing system (pump, tank, and accessories)

1 x large-capacity security filter housing

Complete RO skid with pressure vessels, high-pressure pump, and control panel

Pressure gauges, flow meters, and conductivity monitor

Pre-plumbed piping and valves

User manual and installation guide

💼 OEM/ODM Services

As a professional light-custom water treatment equipment manufacturer, we offer comprehensive OEM/ODM solutions to meet your unique requirements:

Custom flow rates and system configurations

Branding and logo customization

Design modifications for specific feed water conditions

Packaging and documentation tailored to your target market
